Portable monitor 18.5” series User guide

Model: f8a1/f8a2/185fcc

◆ Français manuel voir page 4

◆ Deutsch handbuch siehe Seite 4

◆ Español manual ver página 4

Italiano manuale vedi pagina 4

Loading page 2...

Loading page 3...

Loading page 4...

Transcript of the document

Page 1 - English - : wwwbimawenvip supportbimawenvip 1 Portable monitor 185 series User guide Model f8a1f8a2185fcc Français manuel voir page 4 Deutsch handbuch siehe Seite 4 Español manual ver página 4 Italiano manuale vedi pagina 4
Page 2 - English - : wwwbimawenvip supportbimawenvip 2 Note Please use the original adapter and cables to connect the monitor to avoid display errors For example low brightness white screen splash screen etc Resolution 19201080 169 Refresh rate 60hz 100hz120hz It depends on the eaxt model Brightness 300cd Size 185 inch Demension423mm249mm10mm Monitor Weight 1100g not include the leather case and accessories ① Power Return button Long press off display short press the button to return ② Signal light ③ OSD wheel3 directions of the menu wheel can adjust Press towards can open OSD menuenter submenu switch menu on same class Press ① power button to save and return to main menu Pull up and down the wheel directlyto adjust the brightness Pull down and up the wheel directly to adjust the volume ④ 35mm earphone hole Headphone speaker extension interface ⑤ MiniHDMI interface used for audio and video signal transmission ⑥ ⑦Fullfeature USB31 TYPEC interface for power audio and video signal transmission reversible insertion ability Interface
Page 3 - English - : wwwbimawenvip supportbimawenvip 3 Equipment connection reference Models compatible httpswwwbimawenvipmodels 1 Connect with fullfeatured TypeC 2 Connect to mobile phones with signal output The display supports connecting to Nintendo using a standard cable to switch TV mode switching The monitor will be connected to a 5V power supply by an external charging power source to 720p The monitor and switch will run through an external power supply to the 15VPD protocol power supply the switch is charged the resolution is 1080p 3 Connect to a computer with HDMI interface TYPEC transfer TypeC TYPE C To Type C Power 5V1A and above Video audio signal Mini HDMI to HDMI TYPE C transfer USBA Touch screen signal and power If the computer USB interface is inadequateUse 5V3A to connect to an external power supply 4 Connect to multiple HDMI devices Video audio signal Mini HDMI to HDMI
Page 4 - English - : wwwbimawenvip supportbimawenvip 4 Email supportbimawenvip httpswwwbimawenvipf8a Use original adapter to connect to external power Video audio signal Mini HDMI to HDMI Use 5V3A to connect to external power Video game equipment does not support touch screen functions When the display is connected to the HDMI device via HDMI devices it can be used as a TV working HDMI cable the monitor can pass through an external power supply or through the HDMI device via its USB port if the USB port has sufficient wattage Remarks The TypeC interface above the screen is a fully fully equipped USB 31 has an electrical interface The lower TYPEC interface is an auxiliary power interface In general give priority to the T y P E C interface powered by the device When connecting the display to the HDM i interface connect the power supply first and then connect the HD TV cable to ensure signal fluent The display will switch to energy saving mode and display brightness to use fullfeature typec to automatically adjust to a 30 single connection interface The user can be based on the environment If you cant adjust the brightness turn off the HDR Français manuel Deutsch handbuch Español manual Italiano manuale
