Technical Manual for Conlog BEC62(08) Three Phase Prepaid Meter

2024-11-25 • 0 likes • 1 views

CClementina Bode

The BEC62(08) is a three-phase, four wire, STS compliant prepayment electricity meter ideal for residential, commercial and light industrial electricity metering applications.
The device is also termed a “split” meter, consisting of two items; the MCU (measurement control unit and the UIU (User interface unit). The MCU is installed outside the customer premises in a meter box or kiosk, while the UIU sits inside the customer premises.
The BEC62(08) solution provides a number of innovations, the split function serves as a great advantage to the utility as access to the meter is restricted, thereby reducing the chance of meter tamper. The unit also has a wide range of programmable functions, to provide a high level of customisation for each utility.

1 of 59

Information in this document is subject to change without notice and does not represent a commitment on the part of Conlog. No

part of this document may be reproduced, transmitted, transcribed or translated into any language without express written

permission of Conlog. Conlog (Pty) Ltd Reg. No. 1982/011895/07

BEC62 (08)

Technical manual

Document number: 01 0005 6000 R00

Loading page 2...

Loading page 3...

Loading page 4...

Loading page 5...

Loading page 6...

Loading page 7...

Loading page 8...

Loading page 9...

Loading page 10...

Loading page 11...

Loading page 12...

Loading page 13...

Loading page 14...

Loading page 15...

Loading page 16...

Loading page 17...

Loading page 18...

Loading page 19...

Loading page 20...

Loading page 21...

Loading page 22...

Loading page 23...

Loading page 24...

Loading page 25...

Loading page 26...

Loading page 27...

Loading page 28...

Loading page 29...

Loading page 30...

Loading page 31...

Loading page 32...

Loading page 33...

Loading page 34...

Loading page 35...

Loading page 36...

Loading page 37...

Loading page 38...

Loading page 39...

Loading page 40...

Loading page 41...

Loading page 42...

Loading page 43...

Loading page 44...

Loading page 45...

Loading page 46...

Loading page 47...

Loading page 48...

Loading page 49...

Loading page 50...

Loading page 51...

Loading page 52...

Loading page 53...

Loading page 54...

Loading page 55...

Loading page 56...

Loading page 57...

Loading page 58...

Loading page 59...

Transcript of the document

Page 1 - English - : All Rights Reserved 2013 Information in this document is subject to change without notice and does not represent a commitment on the part of Conlog No part of this document may be reproduced transmitted transcribed or translated into any language without express written permission of Conlog Conlog Pty Ltd Reg No 198201189507 BEC62 08 Technical manual Document number 01 0005 6000 R00
Page 2 - English - : BEC62 08 technical manual Table of contents BEC6208 product overview 4 The measurement control unit MCU 5 What the LEDs mean 5 Virtual token carrier VTC 6 Direct probe port type A 6 Flags probe port 6 The user interface unit UIU 7 LCD interface 8 Product specifications 10 Installing the meter 12 Installing the metering device MCU 12 Wiring instructions 13 Installing the user interface unit UIU 14 Installing a wireless solution 16 Installing the wUIU 16 Pairing the wUIU to a meter 18 Checking the wUIU signal 19 Installing and pairing the wUIU to a wireless extender WEX 20 Testing the meter installation and sealing the device 22 Commissioning the meter 23 Checking if the meter is commissioned 23 Features of the meter 24 Security 24 Reliability 24 Protection 24 Under and over voltage measurement 24 Current measurement 25 Temperature measurement 25 Nominal voltage measurement 25 Power overload 25 Phase unbalance power overload 25 Thermal overload 25 Over voltage and under voltage 26 Current overload 27 Extreme current overload 27 Tamper 27 Tamper status 28 Number of tamper events 28 General icon indications 29 Low credit indication 29 Zero credit indication 29 Negative credit indication 29 Token acceptance indication 30
Page 3 - English - : BEC62 08 technical manual System busy hourglass indication 30 Accessing information on the meter using short codes 31 Entering a short code 31 Viewing the meters serial number 32 Viewing consumption information 32 Meter total to date MTTD and user total to date UTTD 32 Average power in kW 33 Average current per phase 34 Average voltage per phase 35 Time remaining to 0 kWh credit 36 Total user consumption to date 37 Total user credit entered to date 37 Estimated average daily and 30 day consumption 37 Last hour last 24 hours and last 30 days consumption 38 Display tamper detection counter 38 Viewing STS token information 39 Last ten meter specific tokens entered 39 Value and ID of the last credit token entered 40 Troubleshooting 41 Disconnection of supply 41 Automatic disconnection 41 Reason for last disconnect 42 Token error indication 43 STS token result 47 Short code index 48 Standard definition items 48 Manual configuration items 50 Status and measure items 52 Factory configurable items 53 Operational statistics 54 STS tokens 55 Meter error codes 55 STS class one tokens 55 STS class two tokens 56 Industrial standards 57 Company overview 58 Contact information 59
Page 4 - English - : BEC62 08 technical manual BEC6208 product overview The BEC6208 is a threephase four wire STS compliant prepayment electricity meter ideal for residential commercial and light industrial electricity metering applications The device is also termed a split meter consisting of two items the MCU measurement control unit and the UIU User interface unit The MCU is installed outside the customer premises in a meter box or kiosk while the UIU sits inside the customer premises The BEC6208 solution provides a number of innovations the split function serves as a great advantage to the utility as access to the meter is restricted thereby reducing the chance of meter tamper The unit also has a wide range of programmable functions to provide a high level of customisation for each utility Figure 1 The BEC6208 MCU and UIU Item Measurement control unit MCU or meter User interface unit UIU Mounting BS footprint Bracket Installation Meter box kiosk or similar external to consumer premises Wall mounted inside consumer premises
Page 5 - English - : BEC62 08 technical manual The measurement control unit MCU What the LEDs mean Communication status LED yellow This indicates that there is communication between the meter and the UIU LED is flashing data is being received and transmitted between the meter and the UIU LED is permanently off there is no communication between the meter and the UIU LED is permanently on there is a short circuit on the communication cable between the meter and the UIU Power load status LED green This LED has a dual function it indicates that the meter is powered and also indicates if the consumers supply is connected LED is permanently on the meter is powered and the consumers supply is connected LED is flashing the meter is powered but the consumers load is disconnected LED is off the meter is not powered and the consumer has no supply Communication status LED Power loadstatus LED Rate LED Flags probe port Meter serial number Terminal cover Location for security seals
Page 6 - English - : BEC62 08 technical manual Rate LED red This LED has a dual function it indicates the rate of consumption and is also used to verify the accuracy of the meter The LED flashes faster to indicate a rapid consumption of electricity The LED pulses 1000 times for every kWh of energy measured Virtual token carrier VTC The BEC6208 meter supports two VTC interfaces Direct probe port type A This port is primarily used to extract data from an uninstalled meter using a handheld unit as it enables the interrogator unit to supply power to the meter The physical port is shared with the flags port therefore only one channel can be used at a time The flags port takes priority Flags probe port This port is primarily used to extract data from an installed meter using a handheld unit The physical port is shared with the direct probe interface therefore only one channel can be used at a time The flags port takes priority This port is optically isolated so you are protected and totally isolated from the mains supply This port only operates when the meter is powered You cannot power the meter through this interface
Page 7 - English - : BEC62 08 technical manual The user interface unit UIU The UIU is installed in the consumer premises connected via two communication wires to the MCU meter The meter is usually located outside the building The UIU has a twopart construction the base and the numeric keypad with LCD display The numeric keypad is used to enter tokens and initiate user functions Note The communication cables between the meter and the UIU are not polarity sensitive LCD Display Keypad Backspace key Rate LED Hash key Sealing bung
Page 8 - English - : BEC62 08 technical manual LCD interface The UIU has an LCD screen that displays consumer data and meter information To view all icons on the display enter 002 on the keypad The icons on the display indicate the following 1 Bar indicator representing Consumption Abnormal trip Menu item 2 Token or short code entry accepted indicator 3 Short code entry 4 Consumers electricity supply connection indicator 5 System busy 6 Token required 7 Emergency credit indicator life line mode 8 Token or short code entry rejected 9 Manual reconnection required 10 Technical assistance required 11 Low battery indicator if applicable 12 Timed load reduction indicator 13 Currency units indicator 14 Units of measurement 15 Over temperature indicator
Page 9 - English - : BEC6208 technical manual Bar indicator The bar indicator represents one of the following depending on the information displayed Consumption Each segment of the bar indicator represents 10 of the maximum permissible load For example if the load limit is set to 164kW then each segment represents 16kW Abnormal trip If a consumers supply is disconnected due to an abnormal trip condition the segments of the bar indicator flash Menu item When you are viewing information about a selected function that requires more than one screen to display all information the segments of the bar indicator represent the screen display you are viewing
Page 10 - English - : BEC6208 technical manual Product specifications Voltage ratings per phase Nominal voltage 20 15 110 127 V AC 220 240 V AC Supply frequency 5 60Hz 50Hz Current ratings Base current I b 10A 10A Maximum current I max 100 A 100A Minimum starting current Class 1 Class 2 40mA 40mA 50mA 50mA Utilisation category UC2 UC2 Nominal power consumption 16 W 9 VA 16 W 9 VA Accuracy Class 1 or 2 maintained throughout life of product Over voltage rating 18 times the nominal voltage for 48 hours Short circuit rating Shortcircuit withstand 30 kA Protection Power overload Thermal overload Current overload Galvanic isolation Overunder voltage Tamper protection Phase imbalance Environmental Operating temperature 10C to 55C Storage temperature 25C to 70C Humidity 95 noncondensing IP rating IP 54 RF immunity 30 Vm Status indicators Power load status LED Rate LED 1000 pulses kWh Communication status LED
Page 11 - English - : BEC6208 technical manual Installation Footprint BS 7856 Asymmetrical Insulation class Double insulation Terminals Live Neutral Common Type Cage clamps Cage clamp Spring clamp Size 25mm² 25mm² 07mm² Interrogation Type Flags probedirect probe Security Meter housing Security seals Terminal Cover Serialised plastic security sprung lock seals Tamper protection Tamper terminal cover Load disconnection on tamper detection No power tamper optional Packaging Units per carton 1 per carton Carton weight including box 13 kg For further packaging information please contact Conlog Standards IEC 62051 IEC 6205552 STS 1011 IEC 6205211 BS 7856 DSP 341527 IEC 6205321 SANS 15241 ISO 9001 IEC 6205521 SANS 152411 ISO 14001 IEC 6205531 SANS 152412 OHAS 18001 IEC 6205541 SANS 15244 IEC6205621 IEC 6205551 SANS 15417 Note There are two sizes of terminal covers available a long and short version The long cover has cable entry from the back of the meter where as the short cover has cable entry from the bottom of the meter
Page 12 - English - : BEC6208 technical manual Installing the meter Installing the metering device MCU Important Before installing the meter take note of the following precautions The wiring must be performed by a certified installation electrician and must conform to the prevailing government standards and safety regulations This product is not a protection device and so requires the use of a suitable upstream and downstream breaker When wiring the meter ensure that the incoming supply is isolated by switching off the upstream breaker We recommend that if you are connecting aluminium cables to this product use bi metal lugs We recommend that the meter is installed in an enclosure with an IP54 rating or higher For installation of the UIU see Installing the User Interface Unit UIU section or refer to the installation guide shipped with the device Cabling specification Cable Size Live and Neutral Maximum 25mm Communication Maximum 07mm Single core recommended Tools and accessories required for the wall mounting installation 1 x 6mm insulated terminal screwdriver 1 x Insulated side cutters 1 x Electric drill 1 x Masonry drill bit Ø7mm 3 x wall plugs and screws Ø7mm x 30mm 8 x bimetal lugs if aluminium cables are used
Page 13 - English - : BEC6208 technical manual Wiring instructions 1 Connect the incoming neutral to terminal 10 of the meter 2 Connect the incoming live phase 1 to terminal 1 of the meter 3 Connect the incoming live phase 2 to terminal 4 of the meter 4 Connect the incoming live phase 3 to terminal 7 of the meter 5 Connect the outgoing neutral to terminal 11 of the meter 6 Connect the outgoing live phase 1 to terminal 3 of the meter 7 Connect the outgoing live phase 2 to terminal 6 of the meter 8 Connect the outgoing live phase 3 to terminal 9 of the meter 9 Connect the communication wires for the UIU to terminals 12 and 13 by pushing back on the orange clips insert the communication wires into the terminal holes and release Figure 2 MCU terminal diagram Note Terminal 12 and 13 are not polarity sensitive
Page 14 - English - : BEC6208 technical manual Installing the user interface unit UIU 1 Place the wall mount bracket against the wall ensuring that the unit is level and that the communication cable can pass through the cable entry hole Figure 31A 2 Mark and drill 6mm holes for the two mounting holes and insert the wall plugs Figure 31B 3 Pull the communication cable through the cable entry hole Ensure that no more than 100mm of cable is protruding 4 Insert and tighten all screws ensuring the base is securely fastened in position and is not twisted or distorted 5 Cut and strip the ends of the communication cable To ensure a good connection we recommend that at least 15mm of cable is stripped 6 Connect the communication wires for the UIU by pushing back on the orange clips and inserting the wires Figure 32A 7 Curl up the surplus communication cable ensuring that it does not get damaged when securing the unit to the bracket 8 Slide and clip the unit onto the base Figure 33A 9 Insert and tighten all screws ensuring that the unit is securely fastened in position Figure 33 B Figure 31 UIU base view Mounting bracket holes Communication cable entry point
Page 15 - English - : BEC6208 technical manual Figure 32 UIU back view Figure 33 UIU side view Communication cable connector block 15mm stripped communication cable Slide and clip into base Optional communication cable entry point Screw into base and insert security seal
Page 16 - English - : BEC6208 technical manual Installing a wireless solution The BEC6208 can be converted into a wireless meter through the addition of a Wireless Meter Interface WMI which enables RF communication from the meter to the Wireless User Interface Unit wUIU It is important to note that the wireless solution requires a wUIU to be installed in the consumers home To install the wireless meter interface WMI The WMI is installed close to the meter to enable RF communication The WMI can be installed on a pole with cable ties or within a pole top box on a DIN rail When installed in an unobstructed environment a distance of up to 150 metres line of sight can be achieved between the two devices Once positioned the communication cables from the WMI are connected onto the meter terminals 12 and 13 by pushing back the orange clips The terminals are not polarity sensitive See Figure 2 Wiring instructions Installing the wUIU Important The wUIU can be used with the 09 series meters as well as wirelessenabled 05 or 08 generation meters 1 Place the wall mount bracket against the wall ensuring that the unit is level Figure 41 2 Mark and drill 6mm holes for the two mounting holes and insert the wall plugs Insert and tighten all screws ensuring that the unit is securely fastened in position and that the unit is not twisted or distorted 3 Insert the batteries into the back of the wUIU and secure the cover with the supplied screws Figure 42 4 Slide and clip the unit onto the base Figure 43
Page 17: BEC6208 technical manual Figure 41 wUIU Base view Figure 42 Insert batteries Mounting bracket holes
Page 18 - English - : BEC6208 technical manual Figure 43 Slide wUIU into bracket Pairing the wUIU to a meter Pairing the wUIU with a meter A new wUIU previously unpaired will show the following display once powered Enter the 11 digit meter serial number The numbers will scroll across the display as the digits are entered When the serial number has been entered the wUIU starts communication If the pairing with the meter is successful the following will be displayed the meter will then return to its default screen This display indicates the pairing was not successful this may be due to a range problem or a loss of power Following a successful pairing the display will show the default meter information
Page 19 - English - : BEC6208 technical manual Repairing the wUIU with a meter Initiate a new pairing by entering 036 You will see the following display Enter the 11 digit meter serial number As you enter the digits the display will scroll to the left When all digits have been entered the wUIU starts communications If the pairing with the meter is successful the following will be displayed the meter will then return to its default screen If the pairing with the meter is unsuccessful or the incorrect serial number is entered the connection process will fail and abort Following a successful pairing the display will show the default meter information Checking the wUIU signal To check the RF signal strength enter the short code 075 This will display the signal strength for 30 seconds To abort the command hold down the backspace or hash key for three seconds The signal strength is displayed on the bar graph This shows signal strength of 80
Page 20 - English - : BEC6208 technical manual Installing and pairing the wUIU to a wireless extender WEX In some installations it may be necessary to increase the signal between the wUIU and the meter This is achieved by installing a Wireless Extender WEX between the meter and the wUIU to ensure consistent communication between the devices It is recommended that the distance between the WEX and the meter should not exceed 20 metres The WEX can be mounted on an exterior wall or light pole and the device is powered via the mains source 220240V Once connected the WEX can increase the signal to the wUIU to some 200 metres line of sight Following installation it is necessary to pair the WEX Previously unpaired wUIU A previously unpaired wUIU will show the following display once powered Enter the serial number of the WEX As you enter the digits the display will scroll to the left When all 11 digits of the WEX serial number have been entered you will again see the following display Enter the 11 digit meter serial number As you enter the digits the display will scroll to the left When all digits have been entered the WEX starts communications If the pairing with the WEX is successful the following will be displayed If the pairing with the WEX is unsuccessful the following will be displayed Check and confirm the WEX serial number
Page 21 - English - : BEC6208 technical manual Immediately after the successful pairing this display will be momentarily viewed If the pairing with the meter is successful the following will be displayed the meter will then return to its default screen The following screen indicates the pairing was not successful this may be due to a range problem or a loss of power Following a successful pairing the display will show the default meter information Previously paired wUIU If the wUIU is already paired it is necessary to pair the device again with the WEX enter 036 Enter the serial number of the WEX As you enter the digits the display will scroll to the left When all 11 digits of the WEX serial number have been entered you will again see the following display Enter the 11 digit meter serial number As you enter the digits the display will scroll to the left When all digits have been entered the WEX starts communications
Page 22 - English - : BEC6208 technical manual If the pairing with the WEX is successful the following will be displayed If the pairing with the WEX is unsuccessful the following will be displayed Check and confirm the WEX serial number Immediately after the successful pairing this display will be momentarily viewed If the pairing with the meter is successful the following will be displayed the meter will then return to its default screen The following screen indicates the pairing was not successful this may be due to a range problem or a loss of power Following a successful pairing the display will show the default meter information Testing the meter installation and sealing the device 1 Fit the terminal cover taking care not to damage the tamper switch post Tighten the piston head screws of the terminal cover Do not fit the security seals 2 Before testing the installation ensure that the UIU has been installed and connected 3 Apply power to the meter by closing the upstream breaker 4 The communication LED yellow will flash indicating that there is communication between the meter and the UIU and the UIU will display the available credit 5 The load status LED green will indicate the status of the consumers supply If the LED is on then the consumer supply is connected If flashing the consumers supply is disconnected 6 In some cases the meter may require a commissioning token to connect the consumers supply Refer to Checking if the meter is commissioned to determine whether the meter requires commissioning If the meter requires commissioning refer below to Commissioning the meter
Page 23 - English - : BEC6208 technical manual 7 Confirm that the serial number printed on the meter barcode label and the identification card is correct by typing 100 on the UIU and comparing these 8 If the meter is working correctly insert the supplied security seals Commissioning the meter Important If the meter is has not been commissioned the consumers electricity supply remains disconnected regardless of the credit state of the meter The commissioning token number is 1275 4194 1448 6450 5970 and is not meter specific and therefore can be used on all Conlog STS meters Alternatively the short code 043 can be used for wireless installations The decision to configure a meter with the commissioning function is made when the meter order is placed and the meter is manufactured at Conlog The benefit of an uncommissioned meter is that you can conclude the installation and apply the incoming electricity supply without the meter going into a tamper state This means you do not need to carry meter specific tamper tokens and wont experience unnecessary delays in concluding an installation After you have verified the installation as described in the Testing the meter installation and sealing the device section enter the commissioning token or short code on the UIUs keypad Once this is entered tamper detection is active and the consumers electricity supply is connected Checking if the meter is commissioned Short code 031 If the meter is supplied in a commissioned state it will detect tamper as soon as the electricity supply is connected If it is supplied in an uncommissioned state it will not detect tamper until the meter is commissioned To determine if the meter has been commissioned Enter 031 on the keypad Meter has been commissioned Meter has not been commissioned
Page 24 - English - : BEC6208 technical manual Features of the meter Security There is provision for serialised security seals in combination with sacrificial plastic seals The meter is completely sealed to prevent tampering Tamper can be detected even if supply is disconnected optional The user Interface incorporates a shortcut key to display the number of tamper conditions detected The meter has an internal register of correctly entered meter specific tokens to prohibit the replaying of tokens Each meter has a unique meter security key The terminal cover has a tamper detection feature The meter can be commissioned at installation optional Reliability Conformalcoated PCBs ensure protection against the ingress of insects dust and humidity The UIU has a proven reliability of more than one million operations per key Pick and place technology using surface mounted components ensures a high degree of manufacturing accuracy repeatability and reliability The meter accuracy is maintained over the life of the meter Protection Each phase is protected by a 5kA 5kV surge arrestor The electronic circuits are designed to withstand 420VAC for up to 48 hours The meter is equipped with thermal protection on the terminals enhancing product safety and the meters life cycle The product is designed to suspend electricity supply under power and current overload conditions with a short time over current protection of 30kA and thermal protection The BEC6208 incorporates three 100A latching relays to connect disconnect the consumer supply The following features are employed as protection features for both the consumers appliances and the meter Power unbalanced power and current overloads The supply will be restored automatically 30 seconds after the trip event was registered If the trip event persists then the consumers supply will be disconnected again After 5 attempts to reconnect the consumers supply will be disconnected for 30 minutes Thermal over voltage and under voltage trips The supply will be restored when the trip condition no longer exists for a period of 15 seconds Under and over voltage measurement This setting is a trip threshold that suspends electricity supply when an under or over voltage condition exists The supply is suspended until the voltage conditions return to normal The trip threshold can be configured for both under and over voltage supply conditions The average voltage is calculated every fifteen seconds
Page 25 - English - : BEC6208 technical manual Current measurement Current measured is calculated every 15 seconds and is derived from the average power and the average voltage measured per phase The derived current measurement is used for the over current trip evaluation Temperature measurement The average temperature is calculated every 15 seconds from the samples accumulated and is used for the over temperature trip evaluations Temperature is measured on all phases individually including neutral Nominal voltage measurement The average voltage per phase is measured every 15 seconds from the samples accumulated This value is used for t under and over voltage trip evaluations Power overload Short code 007 If the instantaneous power measured by the meter is higher that the power load limit setting then the meter will disconnect the consumers supply The trip limit can be changed through the use of a meter specific token from a vending unit The power load limit is displayed in kilowatts kW Phase unbalance power overload Short code 010 If the instantaneous power measured between any of the three phases by the meter is higher that the unbalanced power load limit setting then the meter will disconnect the consumers supply The display indicates a maximum phase unbalance limit of 23 kW Thermal overload If the temperature of the busbars on any of the phases including neutral measured by the meter rises above a maximum temperature trip limit default of 120C the meter will disconnect the consumers supply The supply will remain disconnected until such time as the temperature has dropped below a reconnect temperature trip limit of 105C The maximum temperature trip limit is configurable and cannot be set to lower than 55C A value of lower than 55C will be ignored and a trip limit of 55C will be set The maximum temperature trip limit is not configurable and is used to protect the meter
Page 26 - English - : BEC6208 technical manual Over voltage and under voltage Short code 035 This short code displays the under and over voltage limits Under voltage If the average supply voltage measured on any phase by the meter is less than the minimum voltage trip limit the meter will disconnect the consumers supply The supply will remain disconnected until such time as the supply voltage rises above this setting The minimum voltage trip limit is configurable in production and the feature can be disabled by setting the limit to 0VAC Over voltage If the average supply voltage on any phase measured by the meter is higher than the maximum voltage limit the meter disconnects the consumers supply The electricity supply remains disconnected until the voltage drops below this limit The default maximum voltage trip limit is configurable if this value is set to the maximum value example 420VAC the feature will be disabled Menu item 1 indicated by the bar graph displays the under voltage threshold limit Menu item 2 indicated by the bar graph displays indicates the over voltage threshold limit
Page 27 - English - : BEC6208 technical manual Current overload Short code 037 If the current measured by the meter is higher than the maximum current limit setting then the meter will disconnect the consumers supply The maximum current limit setting is derived from the power load limit and the nominal voltage of the meter configured in production The current overload trip limit is displayed in amperes A Extreme current overload In extreme short term current overload conditions the consumer supply will not be disconnected This is to protect the disconnect device from damage Tamper The BEC6208 meter has optional tamper protection that is configured in production If the tamper feature is enabled any attempt to tamper with the meter can result in the consumers supply being disconnected if so configured The supply is only reconnected when a STS clear tamper token is entered into the meter The STS clear tamper token is meter specific When enabled tamper is only active once the meter is commissioned For information on commissioning the meter see the Commissioning the meter section The meter supports two primary modes for tamper detection Standard tamper activates a tamper condition when the meter is powered No power tamper the meter will detect a tamper condition even in the absence of an AC supply The meter is shipped in a decommissioned state to facilitate installation In this mode the tamper feature is disabled to allow the installer to fit and remove the terminal cover without the unit going into tamper Once installation is complete the installer commissions the meter The nopower tamper feature is active and any subsequent removal of the terminal cover with or without the AC supply will result in the meter registering a tamper condition Other configuration options Do not display tamper status if selected the meter does not display the tamper icons when an active tamper condition is detected Do not trip on tamper if selected the meter will record the tamper event but will not disconnect the supply
Page 28 - English - : BEC6208 technical manual Tamper status Short code 008 This function indicates if the meter has registered a tamper condition A 0 indicates the meter has not been tampered with A 1 indicates the meter has been tampered with If the meter is configured to display tamper as is highly recommended the following indicates the meter has been tampered Number of tamper events Short code 274 The number of tamper events are recorded on the meter from the time the meter is commissioned Display indicates the number of tamper events
Page 29 - English - : BEC6208 technical manual General icon indications Low credit indication When the remaining credit in the meter reaches or is lower than the configurable low credit threshold the buzzer will emit two short beeps The audible warning will repeat until silenced by the consumer Silencing the buzzer is achieved by pressing the backspace key for three seconds If credit is not inserted then the audible low credit warning although acknowledged will be repeated approximately every 24 hours Should the UIU power up into a low credit condition the audible warning will restart The hand icon token required will flash indicating that a credit token is needed Zero credit indication When the available credit reaches zero the disconnection switch suspends the supply of electricity to the consumer The token required icon will be permanently displayed Negative credit indication Important When credit is entered into the meter the negative credit value is first deducted from the credit entered and only the balance will be displayed Under certain circumstances eg through switching delays or disconnection switch failure the consumer may continue consuming power after all remaining credit has been consumed This consumption is registered in the meter as negative credit and is displayed as a negative reading alternatively the meter can be configured at the time of manufacture so that the display continues to indicate 000 kWh whilst the meter registers the negative credit The token required icon continues to be displayed and the supply status icon is not displayed An example of a negative credit display is given below
Page 30 - English - : BEC6208 technical manual The display indicates a negative credit reading of negative 623781 kWh Token acceptance indication The token accepted icon appears briefly after the consumer finishes keying in a 20 digit token or a three digit short code and the token is accepted If the audible feedback option is installed a short 60 millisecond beep will be heard System busy hourglass indication When the system busy icon appears the keypad is disabled The consumer must wait until the icon disappears before entering data
Page 31 - English - : BEC6208 technical manual Accessing information on the meter using short codes To access information on the meter short codes are used These enable you to extract information from the meter without using specialised equipment The short codes are a sequence of three numeric digits bound by two hash commands that you enter on the meter using the keypad example 003 When you enter a short code you do not need to include the preceding zeros For example instead of entering 041 or 002 you can use 41 and 2 When a short code returns more than a single item of information you can scroll to view more information using the hash key When you scroll the segments of the bar indicator represent the menu item you are viewing So one segment in the bar indicates menu item 1 two segments in the bar indicate menu item 2 and so on To return to the default display when you are viewing additional information press the backspace key Example This example shows the meter total to date and the user total to date respectively Menu item 1 displays the meter total to date As shown in this image the bar indicator has one segment displayed indicating menu item 1 Menu item 2 displays the user total to date As shown in this image the bar indicator has two segments indicating menu item 2 For a quick reference of all short codes see the Short codes index section Entering a short code To enter a short code 1 Press on the keypad 2 Enter the required short code 3 Press The requested information is displayed 4 Press to scroll through the information displayed when a short code returns more than a single item of information The segments of the bar indicator represent the menu item you are viewing
Page 32 - English - : BEC6208 technical manual Viewing the meters serial number Short code 100 The serial number displayed should match the serial number printed on the barcode label of the meter and the identification card The meter serial number will scroll from right to left Viewing consumption information The BEC6208 meter provides historical and predictive views of consumption based on the historical data You can access this information using short codes Meter total to date MTTD and user total to date UTTD Short code 004 MTTD This is the total measured consumption for the life of the meter It is calculated in 100 Wh increments and the value cannot be cleared UTTD This is the total measured consumption for the consumer This value is cleared during a clear credit process tenancy change Menu item 1 displays the MTTD Menu item 2 displays the UTTD
Page 33 - English - : BEC6208 technical manual Average power in kW Short code 070 To display the average power consumed Initially the display will show the total average power consumption for all three phases of a three phase meter Pressing the key will display the average power consumption per phase Display indicates a total average power consumption of 1958 kW Display indicates a power consumption of 831 kW for the first phase Display indicates a power consumption of 781 kW for the second phase Display indicates a power consumption of 346 kW for the third phase
Page 34 - English - : BEC6208 technical manual Average current per phase Short code 071 To display the total average current consumption for all phases of a three phase meter Pressing the key will display the average current measured per phase Display indicates a total average current consumption of 112 Amps Display indicates a current consumption of 192 Amps for the first phase Display indicates current consumption of 102 Amps for the second phase Display indicates a current consumption of 318 Amps for the third phase
Page 35 - English - : BEC6208 technical manual Average voltage per phase Short code 072 To display the average voltage measured on each phase of the meter Pressing the key will display the average voltage measured on each phase Display indicates a voltage consumption of 280 Volts for the first phase Display indicates a voltage consumption of 210 Volts for the second phase Display indicates a voltage consumption of 180 Volts for the third phase
Page 36 - English - : BEC6208 technical manual Time remaining to 0 kWh credit Short code 074 Actual time remaining This is the actual time remaining until credit depletion based on the consumers rate of consumption The time value is displayed as days hours or both depending on the amount of time that is remaining until credit depletion Estimated time remaining This is the estimated time remaining until credit depletion based on the consumers average rate of consumption over the previous 24 hours The time value is displayed as days hours or both depending on the amount of time that is remaining until credit depletion Menu item 1 indicates a time remaining of nine days and 13 hours based on the current instantaneous consumption Menu item 2 indicates a time remaining of nine days and 13 hours based on the average consumption over a 24 hour period Note The meter displays a maximum time of 2730 days
Page 37 - English - : BEC6208 technical manual Total user consumption to date Short code 076 To display the consumption of electricity by the customer in kWh since the last clear credit token was entered The example indicates the total consumption is 598 kWh Total user credit entered to date Short code 077 To display the total user credit entered into the meter since the last clear credit token was entered The example indicates the total credit entered is 739850 kWh Estimated average daily and 30 day consumption Short code 271 Estimated average daily consumption This is a predictive calculation of the consumption for the next 24 hour period It is based on the average consumption over the last seven days of active consumption Estimated average 30 day consumption monthly This is a predictive calculation of the consumption for the next 30 day period It is based on the average consumption over the last seven days of active measurement Menu item 1 displays the estimated average daily consumption Menu item 2 displays the estimated average 30 day consumption
Page 38 - English - : BEC6208 technical manual Last hour last 24 hours and last 30 days consumption Short code 272 Last hour consumption This is the total consumption measured in the last hour Last 24 hour consumption This is the total consumption measured in the last 24 hours Last 30 days consumption This is the total consumption measured in the last 30 days Menu item 1 indicates last hours total consumption Menu item 2 indicates the last 24 hours total consumption Menu item 3 indicates the last 30 days total consumption Display tamper detection counter Short code 274 This function displays the tamper detection counter Every time a tamper condition is detected a counter is incremented The example below indicates a 25 tamper conditions The example indicates a 25 tamper conditions
Page 39 - English - : BEC6208 technical manual Viewing STS token information The BEC62 08 meter provides historical information about STS tokens You can access this information using short codes Last ten meter specific tokens entered Enter short code 251 to 260 to view the last 10 meter tokens specific tokens entered The history includes the 20digit token number the token class sub class and value of the token as applicable The short codes show token history sequentially So code 251 displays the most recent token entered 252 the second most recent 253 the third most recent and so on up to 260 for the tenth most recent token entered into the meter Menu item 1 indicates the token class and sub class Pressing the hash key will then display the actual 20 digit token scrolling from right to left in five groups of 4 digits The full token shown in the display is 0869 2155 0673 4928 Pressing the hash key will then display the transaction amount contained within the token This display will only apply to tokens that contain a transfer amount
Page 40 - English - : BEC6208 technical manual Value and ID of the last credit token entered Short codes 200 and 201 The value of the last credit token entered can be viewed through short codes Value of the last credit token entered ID of the last credit token entered
Page 41 - English - : BEC6208 technical manual Troubleshooting Disconnection of supply Automatic disconnection The BEC6208 meter automatically disconnects the consumers supply in the event of a trip The meter supports the following individual trip events that are registered and saved when the meter trips Trip event type Reconnection type Tamper Automatic reconnection by entering a clear tamper token Thermal overload Automatic reconnection Current overload Automatic reconnection Power overload Automatic reconnection Under voltage Automatic reconnection Over voltage Automatic reconnection Unbalanced power overload Automatic reconnection If more than one trip event is detected only the trip event with the highest priority is recorded You can view the reason for the last highest priority disconnection using the short code 073
Page 42 - English - : BEC6208 technical manual Reason for last disconnect Short code 073 This short code will display the last abnormal trip event that caused the consumers load to be disconnected The trip events are displayed below Power Overload Current overload Unbalance power overload Thermal overload Over voltage Under voltage No abnormal trip registered
Page 43 - English - : BEC6208 technical manual Token error indication Display Description Invalid token This occurs when authentication of a token fails Reason One of the following reasons could be why the token is invalid The meter serial number on the token doesnt match the physical meter number on the meter The tariff index on the token is not the same as the tariff index programmed into the meter The supply group code that the token was made on differs to the supply group code in the meter The token was entered into the meter incorrectly The key revision number of the token differs to the key revision number as programmed into the meter To resolve 1 Check the printout of the token 2 If necessary run the STS0 meter test token 5649 3153 7254 5031 3471 or the short code 000 to compare the parameters of the meter or run a specific item in the test 3 Run 030 for the supply group code SGC 4 All the information should be validated to determine why the token didnt work
Page 44 - English - : BEC6208 technical manual Display Description Duplicate or used token This occurs when a token has the same ID as a token already entered Reason A token with the same token ID is already loaded on the meter To resolve Enter a valid token You can discard this token as it is not valid Display Description Maximum credit limit exceeded This occurs when the credit loaded from a token exceeds the maximum credit limit of the meter Reason This meter cannot accept more credit than the maximum credit limit To resolve The credit associated with the token is not loaded onto the meter You can use the token at another time
Page 45 - English - : BEC6208 technical manual Display Description Expired token This occurs when a token has an ID older than the oldest token loaded on the meter Reason This token has expired and is too old to be loaded on the meter To resolve Enter a valid token You can discard this token as it is not valid Display Description Token processing failed This occurs when the token is accepted by the meter but cannot be processed
Page 46 - English - : BEC6208 technical manual Display Description Expired meter decoder key This occurs when the meter decoder key has expired Reason The unique meter key has expired and this meter cannot accept tokens To resolve The utility must change the meter key by entering a key change token Display Description Credit token with a DDTK key This occurs when the credit token entered is encrypted under a default key DDTK Display Description Display overrun This occurs when the value displayed is greater than the maximum display area of the screen
Page 47 - English - : BEC6208 technical manual STS token result Short code 078 The display indicates a value of 13 which is a CRC error The STS token result indicates the status of the previous STS token entered into the meter The result is stored in the token status register An extract of the status register values is displayed below Value Description of error Reserved for future assignment Accept The token is accepted 1stKCT The first key change token has been entered 2ndKCT The second key change token has been entered Overflow Error Acceptance of the token would cause an overflow of register in the meter Key type error Indicates that the decoder key is possibly being changed from one key type to another which is in violation of the key change rules Format error The format of the token does not comply with the required format Range error The range of the data is outside of the defined range of values Function error The function has not been implementedis not supported by the meter application process Old error Token is expired Used error Token has already been used duplicate Key expired error Meter key has expired DDTK error a transfer credit token may not be processed using a default key type CRC error The data contained in the token cannot be verified and may be corrupted Mfr code error The manufacturer value in the Class 1 token does not match the manufacturer code value for the decoder Token lockout status Token lockout is active Token status not ready The processing of the last token entered via a virtual carrier has not been completed 17255 Reserved for future assignment
Page 48 - English - : BEC62 08 technical manual Short code index Short codes execute commands on the meter to either display information or configure settings For information on how to use short codes see the Accessing information on the meter using short codes section Note Short codes that are not relevant to the 08 platform have been excluded from the list below Standard definition items The STS dispenser test token is a non meter specific code used to perform a series of tests on the meter The test continues to step through the sequence automatically briefly displaying the data shown for each step To perform this test enter the following 20 digit token 5649 3153 7254 5031 3471 To view a specific item simply enter the relevant short code ie 006 to view the tariff index Short code Description Display Dispenser test STS0 This short code initiates the dispenser test Load switch test STS1 Display test STS2 Input device test STS6 pressing 09 the display will be filled with the value of the key as shown Accumulated energy consumption MTTD STS3
Page 49 - English - : BEC62 08 technical manual Short code Description Display Key revision and key type STS4 Tariff index STS5 Maximum power limit STS7 Tamper status STS8 A 0 indicates the meter is not in a tamper state A 1 indicates the meter is in a tamper state To perform these functions tamper detection must be enabled on the meter Available credit Phase unbalance STS11 011 029 STS Reserved NA
Page 50 - English - : BEC62 08 technical manual Manual configuration items Short code Description Display Display the supply group code Determine if the meter is commissioned or uncommissioned or in a tamper state by viewing the status register View the meters low credit warning limit View the meters thermal trip limit This is displayed as an ADC reference value View the meters under or over voltage limits The first menu indicates the under voltage limit The second menu indicates the over voltage limit Pair a wireless user interface unit wUIU or a wireless extender WEX to a wireless meter
