6.3 Fault Detection
YASKAWA ELECTRIC SIEP C710616 38H YASKAWA AC Drive - L1000A Technical Manual 305
Troubleshooting
6
Digital Operator Display Fault Name
oPr
External Digital Operator Connection Fault
• The external operator has been disconnected from the drive.
Note:
An oPr fault will occur when all of the following conditions are true:
Output is interrupted when the operator is disconnected (o2-06 = 1).
The Up/Down command is assigned to the operator (b1-02 = 0 and LOCAL has been selected).
Cause Possible Solution
External operator is not properly connected to the drive.
• Check the connection between the operator and the drive.
• Replace the cable if damaged.
• Turn off the drive input power and disconnect the operator. Then reconnect the operator and turn the drive input power back on.
Digital Operator Display Fault Name
oS
Overspeed
The motor speed feedback exceeded the F1-08 setting.
Cause Possible Solution
Overshoot is occurring.
• Reduce the settings for C5-01 (Speed Control Proportional Gain 1) and increase C5-02 (Speed Control Integral Time 1).
• If using a closed loop vector mode, enable Inertia Compensation.
Inappropriate parameter settings. Check the setting for the overspeed detection level and the overspeed detection time (F1-08 and F1-09).
Digital Operator Display Fault Name
ov
DC Bus Overvoltage
Voltage in the DC bus has exceeded the overvoltage detection level.
• For 200 V class: approximately 410 V
• For 400 V class: approximately 820 V
• For 600 V class: approximately 1040 V
Cause Possible Solution
Deceleration ramp is too short and regenerative energy
is flowing from the motor into the drive.
• Increase the deceleration ramp (C1-02, C1-04, C1-06, C1-08).
• Make sure the braking resistor rating/external braking transistor rating fits the application.
• If an external braking transistor is used, make sure it is connected properly and working as expected.
Fast acceleration ramp causes the motor to overshoot the
speed reference.
• Check if sudden drive acceleration triggers an overvoltage alarm.
• Increase the acceleration ramp (C1-01, C1-03, C1-05, C1-07).
• Increase the jerk setting in C2-02 (decrease if o1-03 > 3)
Surge voltage entering from the drive input power.
Install a DC link choke.
Note: Voltage surge can result from a thyristor convertor and phase advancing capacitor using the same input power supply.
Ground fault in the output circuit causes the DC bus
capacitor to overcharge.
• Check the motor wiring for ground faults.
• Correct grounding shorts and turn the power back on.
Drive input power voltage is too high.
• Check the voltage.
• Lower drive input power voltage within the limits listed in the specifications.
The braking transistor is wired incorrectly.
• Check braking transistor wiring for errors.
• Properly rewire the braking resistor device.
Encoder cable is disconnected. Reconnect the cable.
Encoder cable wiring is wrong. Correct the wiring.
Noise interference along the encoder wiring. Separate the wiring from the source of the noise (often the output lines from the drive).
Drive fails to operate properly due to noise interference.
• Review the list of possible solutions provided for controlling noise.
• Review the section on handling noise interference and check the control circuit lines, main circuit lines, and ground wiring.
Motor hunting occurs.
• Adjust the parameters that control hunting.
• Adjust the AFR time constant (n2-02 and n2-03).
Digital Operator Display Fault Name
PF
Input Phase Loss
Drive input power has an open phase or has a large imbalance of voltage between phases. Detected when L8-05 = 1, 2, 3
(enabled).
Cause Possible Solution
There is phase loss in the drive input power.
• Check for wiring errors in the main circuit drive input power.
• Correct the wiring.
There is loose wiring in the drive input power terminals.
• Ensure the terminals are tightened properly.
• Apply the tightening torque as specified in this manual. Refer to Wire Gauges and Tightening Torque on page 69.
There is excessive fluctuation in the drive input power
voltage.
• Check the voltage from the drive input power.
• Review the possible solutions for stabilizing the drive input power.
There is poor balance between voltage phases. • Stabilize drive input power or disable phase loss detection.
The main circuit capacitors are worn.
• Check the maintenance time for the capacitors (U4-05).
• Replace the capacitor if U4-05 is greater than 90%. For instructions on replacing the capacitor, contact Yaskawa or a Yaskawa
representative.
Check for problems with the drive input power. If drive input power appears normal but the alarm continues to occur, replace
either the control board or the entire drive. For instructions on replacing the control board, contact Yaskawa or a Yaskawa
representative.
Digital Operator Display Fault Name
PF5
Rescue Operation Power Supply Deterioration Error
Cause Possible Solution
During Rescue Operation, either the DC bus voltage
dropped below S4-12 × (S4-13 - 10%), or 100 ms after
triggering Rescue Operation, the DC bus voltage did not
reach S4-12 × S4-13 before the motor started.
• Check the DC bus voltage setting for Rescue Operation (S4-12).
• Lower the speed reference set for Rescue Operation (S4-15).
• Check the backup power supply. It may need to be replaced with another UPS if it has become worn and can no longer provide
enough power.
SIEP_C710616_38H_7_0.book 305 ページ ２０２３年４月２６日 水曜日 午前９時２２分
Loading page 306...
Loading page 307...
Loading page 308...
Loading page 309...
Loading page 310...
Loading page 311...
Loading page 312...
Loading page 313...
Loading page 314...
Loading page 315...
Loading page 316...
Loading page 317...
Loading page 318...
Loading page 319...
Loading page 320...
Loading page 321...
Loading page 322...
Loading page 323...
Loading page 324...
Loading page 325...
Loading page 326...
Loading page 327...
Loading page 328...
Loading page 329...
Loading page 330...
Loading page 331...
Loading page 332...
Loading page 333...
Loading page 334...
Loading page 335...
Loading page 336...
Loading page 337...
Loading page 338...
Loading page 339...
Loading page 340...
Loading page 341...
Loading page 342...
Loading page 343...
Loading page 344...
Loading page 345...
Loading page 346...
Loading page 347...
Loading page 348...
Loading page 349...
Loading page 350...
Loading page 351...
Loading page 352...
Loading page 353...
Loading page 354...
Loading page 355...
Loading page 356...
Loading page 357...
Loading page 358...
Loading page 359...
Loading page 360...
Loading page 361...
Loading page 362...
Loading page 363...
Loading page 364...
Loading page 365...
Loading page 366...
Loading page 367...
Loading page 368...
Loading page 369...
Loading page 370...
Loading page 371...
Loading page 372...
Loading page 373...
Loading page 374...
Loading page 375...
Loading page 376...
Loading page 377...
Loading page 378...
Loading page 379...
Loading page 380...
Loading page 381...
Loading page 382...
Loading page 383...
Loading page 384...
Loading page 385...
Loading page 386...
Loading page 387...
Loading page 388...
Loading page 389...
Loading page 390...
Loading page 391...
Loading page 392...
Loading page 393...
Loading page 394...
Loading page 395...
Loading page 396...
Loading page 397...
Loading page 398...
Loading page 399...
Loading page 400...
Loading page 401...
Loading page 402...
Loading page 403...
Loading page 404...
Loading page 405...
Loading page 406...
Loading page 407...
Loading page 408...
Loading page 409...
Loading page 410...
Loading page 411...
Loading page 412...
Loading page 413...
Loading page 414...
Loading page 415...
Loading page 416...
Loading page 417...
Loading page 418...
Loading page 419...
Loading page 420...
Loading page 421...
Loading page 422...
Loading page 423...
Loading page 424...
Loading page 425...
Loading page 426...
Loading page 427...
Loading page 428...
Loading page 429...
Loading page 430...
Loading page 431...
Loading page 432...
Loading page 433...
Loading page 434...
Loading page 435...
Loading page 436...
Loading page 437...
Loading page 438...
Loading page 439...
Loading page 440...
Loading page 441...
Loading page 442...
Loading page 443...
Loading page 444...
Loading page 445...
Loading page 446...
Loading page 447...
Loading page 448...
Loading page 449...
Loading page 450...
Loading page 451...
Loading page 452...
Loading page 453...
Loading page 454...
Loading page 455...
Loading page 456...
Loading page 457...
Loading page 458...
Loading page 459...
Loading page 460...
Loading page 461...
Loading page 462...
Loading page 463...
Loading page 464...
Loading page 465...
Loading page 466...
Loading page 467...
Loading page 468...
Loading page 469...
Loading page 470...
Loading page 471...
Loading page 472...
Loading page 473...
Loading page 474...
Loading page 475...
Loading page 476...
Loading page 477...
Loading page 478...
Loading page 479...
Loading page 480...
Loading page 481...
Loading page 482...
Loading page 483...
Loading page 484...
Loading page 485...
Loading page 486...
Loading page 487...
Loading page 488...
Loading page 489...
Loading page 490...
Loading page 491...
Loading page 492...
Loading page 493...
Loading page 494...
Loading page 495...
Loading page 496...
Loading page 497...
Loading page 498...
Loading page 499...
Loading page 500...
Loading page 501...
Loading page 502...
Loading page 503...
Loading page 504...
Loading page 505...
Loading page 506...
Loading page 507...
Loading page 508...
Loading page 509...
Loading page 510...
Loading page 511...
Loading page 512...
Loading page 513...
Loading page 514...
Loading page 515...
Loading page 516...
Loading page 517...
Loading page 518...
Loading page 519...
Loading page 520...
Loading page 521...
Loading page 522...
Loading page 523...
Loading page 524...
Loading page 525...
Loading page 526...
Loading page 527...
Loading page 528...
Loading page 529...
Loading page 530...
Loading page 531...
Loading page 532...
Loading page 533...
Loading page 534...
